Researchers have developed a novel dual-band implantable antenna measuring just 5 x 5 x 0.635 mm, capable of functioning at both 0.954 GHz and 2.4 GHz, making it ideally suited for medical applications. This innovative design, employing combined hexagonal and rhombic patches, addresses the growing need for compact wireless communication systems within the body.
The newly developed antenna achieves circular polarization, which enhances its performance and extends its operational bandwidth. Notably, it features a broad axial ratio bandwidth of 24.6%, ensuring reliable signal transmission even as the human body moves, alleviating polarization mismatch issues common with linear-polarized antennas.
According to the authors of the article, "The proposed antenna exhibits the dual-band resonance at 0.954 GHz with linear polarization (LP) property and circular polarization (CP) property at 2.4 GHz." Such dual-band functionality opens doors for advanced medical devices to communicate effectively with external monitoring systems.
One of the primary challenges faced when designing implantable antennas is adhering to safety standards set by the IEEE. The antenna’s specific absorption rate (SAR) measurements comply with the applicable limits, thereby ensuring patient safety. The antenna's gain measurements were equally impressive, recording -31.2 dBi at 0.954 GHz and -28.1 dBi at 2.4 GHz during testing.
This research was conducted by S. Kumaravel and M. Karthikeyan at the Vellore Institute of Technology, India. The antenna design not only addresses the compact size requirement but also integrates effectively with various Internet of Things (IoT) applications, enabling continuous health tracking and real-time data analysis.
The methodology includes the creation of U-shaped slots within the antenna's ground plane, allowing for optimal impedance matching at the necessary frequency bands. This advancement marks significant progress over past designs, many of which struggled with size and efficiency, often leading to high SAR values or ineffective polarization properties.
To validate the effectiveness of this design, the antenna was tested on skin-mimicking gel and minced pork meat, producing results consistent with simulation expectations, thereby demonstrating its real-world applicability. The antenna's performance ensures dependable wireless communication for implants, reducing the necessity for invasive procedures and increasing patient comfort.
With the rise of telemedicine and remote health monitoring, such technological innovations are pivotal. The authors assert, "This combination helps achieve wide axial ratio bandwidth of 24.6%." This capability allows for more precise tracking of health metrics, possibly transforming patient care.
Concluding, the compact implantable dual-band antenna presents multiple advantages for future biomedical applications due to its design efficiency, adherence to safety regulations, and potential for integration with IoT frameworks. The research emphasizes the importance of safety and efficacy, setting the stage for innovative developments within the field of biomedical engineering.
